In most cases, your KitchenAid microwave’s touchpad malfunctions due to the activation of the lock function, a malfunction in the main control board, a deteriorated membrane switch, a stuck key on the membrane switch, or potential damage resulting from misuse.
KitchenAid Microwave Touchpad Problem
| KitchenAid Microwave Problem | Possible Fix |
|---|---|
| 1. You activated the lock function on the microwave. | Check if there’s an “LOC” or “L” on your microwave’s display. If so, press “Cancel” for 3 seconds (till you hear 2 tones). |
| 2. The main control board could be faulty. | First, test the board for continuous current flow (continuity). Replace the main board control if there is no continuity. |
| 3. There could be a problem with the membrane switch. | Replace the membrane switch with a new one. |
| 4. Your KitchenAid microwave could have a key stuck on the membrane. | Replace the membrane switch with a new one. |
| 5. The touchpad itself could be the problem. | Test the touchpad by pressing each key on it. Consider replacing the touchpad if some keys do not respond to touch. |
1. The Touchpad Might Be Faulty
Your KitchenAid microwave’s touchpad malfunction may be attributed to a faulty touchpad itself. When the touchpad is damaged, it fails to transmit command signals to the control board, necessitating the replacement of the touchpad with a new one.
Before proceeding with the replacement of the defective touchpad, it is advisable to perform a diagnostic test to ascertain its condition. Test each button by pressing them individually.
If all buttons respond to touch, it is likely that the touchpad is not the source of the problem. However, if one or more keys fail to respond, it is recommended to procure a replacement touchpad.
To initiate the touchpad replacement process, follow these steps:
- Unplug the microwave from the power source.
- Begin the disassembly process by removing the grill and then the control panel from the front of the microwave.
- Prior to removing the touchpad, determine if it can be detached by snapping it out or if it is secured in place with screws.
- Disconnect any wire connections from the touchpad.
- Install the new touchpad and ensure the wires are connected correctly.
- Reattach the new touchpad to the microwave and secure it in place with screws.
- After completing the repair, reconnect the microwave to the power source and restore power.
2. The Lock Function is Active
KitchenAid microwaves incorporate a range of safety features, including the child lock function, which serves the purpose of preventing unsupervised operation by children when you’re not present.
When the lock function is activated, the microwave ceases to respond to any touchpad inputs, presuming that it’s your child attempting to use the appliance. You can recognize the activation of the child lock if you observe indicators like “LOC,” “L,” or a padlock symbol on the user interface, signifying that the child lock feature is enabled and consequently deactivating the touchpad.
To disable the lock function, follow these steps:
- Press and hold the “CANCEL” key for approximately 3 seconds.
- You should hear an audible confirmation indicating that the lock function has been turned off.
Pros and Cons of KitchenAid Microwave
Pros
- Brand Reputation
- Versatile Cooking Options
- Build Quality
- Stylish Design
Cons
- Price
- Limited Budget Options
- Size and Space
- Complexity
Differences Between KitchenAid Microwave and Miele Microwave
KitchenAid
KitchenAid microwaves offer a variety of cooking options and features, including sensor cooking, convection cooking, and specialized settings for different types of food.
Miele
Miele microwaves are known for their advanced technology, precision cooking, and innovative features, such as combi-microwave ovens that combine microwave and convection cooking.
Alternative to KitchenAid Microwave
Panasonic
Panasonic microwaves are known for their reliability and innovation. They offer various models with features like inverter technology, sensor cooking, and a wide range of sizes to suit different needs.
3. The Main Control Board Could Be Faulty
If the touchpad on your KitchenAid microwave is unresponsive, it might be due to a malfunction in the main control board.
It’s essential to note that issues with the main control board are relatively uncommon. However, if you’ve exhausted all other troubleshooting options for your KitchenAid microwave without success, replacing the control board may become your last resort.
Fortunately, you can easily find replacement main control boards for KitchenAid microwaves online. Additionally, the process of replacing the board is straightforward. Here are the steps to follow:
- Start by unplugging the power cord to ensure safety.
- Use a screwdriver to remove the screws securing the grill and take it off.
- Open the microwave door and unthread the mounting screws that hold the control panel in place.
- Detach the control panel.
- Free the hinge tab from the control panel.
- Disconnect the ribbon connector that links the main control board to the touchpad and control panel.
- Unthread the mounting screws that secure the control board to the control panel housing.
- Remove the old control board from the control panel housing. Make sure to remove any protective covers from the new main control board before installing it. Position the new main board in the control panel housing and secure it with screws.
- Reconnect the ribbon connector to the new main board.
- Reassemble the unit, ensuring that all wires are connected to their respective terminals.
4. The Membrane Switch Might Be Faulty
A malfunctioning membrane switch could also be a potential cause of unresponsive keys on your KitchenAid microwave’s touchpad.
The touchpad membrane consists of two thin plastic layers, each containing a conductive substance. These layers are separated by a small space until you touch a key on the touchpad. When the two layers make contact, a signal is sent to the control board, instructing the microwave to execute a command.
Over time, these two layers can wear down, and it eventually reaches a point where they cannot establish a proper connection, resulting in the touchpad’s failure to function.
Regrettably, a damaged membrane switch is challenging to repair, and the most practical solution is to replace it.
If you have experience working with appliances, replacing the touchpad membrane switch should not be overly complicated. However, it’s essential to exercise caution during the repair process to avoid the risk of electric shocks.
Here are the steps to replace the touchpad membrane switch:
- Disconnect the microwave from the power socket to ensure safety.
- Use a screwdriver to remove the screws securing the front grill.
- Remove the microwave cabinet to access the inner components of the microwave.
- Unthread the screws holding the front control panel. Disconnect the wires and unscrew the grounding wire and washer.
- Once the control board is exposed, locate the touchpad membrane and carefully detach it from the control board.
- Clean off any residual glue that previously held the old touchpad membrane in place on the control board.
- Peel off the paper covering the adhesive on the new touchpad membrane and attach it to the control board in the same position as the old one.
- After securing the touchpad membrane, connect all the wires, including the grounding wire. Position the control panel and secure it with screws.
- Reattach the front grill.
- With the repair completed, restore power to the unit and test if the touchpad is now functioning correctly.
5. A Key Stuck on the Switch Membrane
An additional potential cause of your microwave’s unresponsive touchpad is when a key becomes stuck after being pressed.
In this situation, if one key gets stuck, it can disrupt the functionality of other keys on the touchpad. Microwaves typically cannot register multiple key presses simultaneously.
To address the issue of a stuck key, you’ll need to disassemble the microwave, remove the control panel, and extract the touchpad for a visual assessment of the touchpad membrane to determine if a key is indeed stuck.
If you confirm that a key is stuck, the solution involves replacing the touchpad membrane. To do this, you can simply follow the steps outlined for problem number 4 in this guide.
Read Also: New Samsung Dryer not Heating
Conclusion
Unresponsive or malfunctioning touchpads in KitchenAid microwaves can be attributed to several potential issues. These include a faulty touchpad, a malfunctioning main control board, a damaged membrane switch, or a key that has become stuck after being pressed. It’s essential to diagnose the specific problem accurately to determine the appropriate solution.
While the touchpad itself can be replaced if it’s the source of the issue, the main control board, though rarely problematic, can also be replaced if needed. A damaged membrane switch, which can occur due to wear and tear, may require replacement. If a key is stuck, this can affect the functionality of the entire touchpad, and the solution is to replace the touchpad membrane.
Each of these issues may necessitate disassembling the microwave to access the components requiring replacement or repair. It’s important to exercise caution when working with electrical appliances and to follow specific steps and safety measures to ensure a successful repair or replacement. Ultimately, a thorough diagnosis and appropriate action can help restore the functionality of your KitchenAid microwave’s touchpad.
