Maytag Bravos Xl Washer Lid Lock Problems

If you're encountering difficulties with the lid lock of your Maytag Bravos XL washer, it's important to continue reading. We suggest practical solutions tailored to specific issues that may aid in resolving a variety of problems related to the Maytag Bravos XL washer's lid lock.

Maytag Bravos XL washer lid lock problems and suggested fixes

Maytag bravos xl lid lock clicking

In most cases, when you hear a clicking sound from the lid lock, it's typically an indication that the lid lock is not properly aligned.

Recommended solution:

1. Attempt to gently manipulate the lid and the latch to ensure they snap into place.
2. If the clicking persists, keep the lid held down until you hear the second click before releasing it.

Here's the reasoning behind this approach: Before commencing a cycle, the washer engages in a sequence of actions involving locking, unlocking, and relocking the lid to assess the effectiveness of the locking mechanism. Consequently, your washer may be shifting out of position before achieving the second lock.

3. It's also plausible that the issue lies with the lid lock assembly. Nevertheless, before jumping to conclusions, conduct a resistance test on the lid lock switch.

For detailed instructions on how to perform this evaluation, please refer to the section labelled "Testing the Lid Lock Assembly" at the conclusion of this post.

It's important to note that if the results of your test indicate a fault in the assembly, you will need to consider replacing it.

Maytag bravos xl washer lid lock flashing

You may notice that the flashing light is often accompanied by an error code, which can greatly facilitate the identification of the underlying issue. This is particularly helpful because each error code is associated with a particular problem and has a distinct repair procedure.

In the following sections, we will examine the common error codes that are indicative of lid lock issues in your Maytag Bravos washer and provide troubleshooting steps for each one.

F5E1: lid switch fault

This error occurs when the lid is locked, but the switch is open, meaning that the control board does not detect the switch as being closed.

Recommended solution:

To address this error, open the washer and ensure that the lid switch wire harness is securely and correctly connected.

F5E2: lid lock fault

This code usually indicates that the lid has not securely moved into the locked position.

Recommended solution:

To resolve this issue, first check for any obstructions that might be preventing the lock striker from engaging properly.

Additionally, use a damp cloth to clean the area around the lock striker, as there may be lint or detergent buildup that is hindering the lock mechanism from sliding into place.

Read Also: http://Why Your Mitsubishi Aircon Stopped Working

Pros and Cons of maytag bravos xl

Pros

• Large Capacity
• Efficient Cleaning
• Multiple Wash Options
• Energy Efficiency

Cons

• Higher Cost
• Size
• Complex Features
• Possible Repairs

Differences Between maytag bravos xl washer and Kenmore Washers

Maytag Bravos XL washers

Maytag Bravos XL washers are known for their larger drum capacity, energy-efficient features, and multiple wash cycle options.

Kenmore

Kenmore offers a wide range of washer models, and the features can vary significantly between models. Some Kenmore washers are designed for basic functionality, while others come with advanced features such as steam cleaning, app-based control, and more.

Alternative to Maytag bravos XL washer

Speed Queen Washer

Speed Queen is a brand known for its durable and commercial-grade washing machines. They are often preferred for their longevity and ruggedness.

F5E3: lid unlock fault

This code typically indicates that the lock has not shifted into the unlocked position.

Recommended solution:

To address this issue, first ensure that there are no obstructions or interference with the lock striker.

Also, double-check that there is no weight or heavy object directly above the lock striker, such as a loaded laundry basket, which may be preventing it from moving freely.

F5E4: lid not opened between cycles

This code is typically displayed when you press the start button for multiple consecutive wash cycles without opening the lid.

Recommended solution:

To resolve the error, open the lid and remove the laundered clothing.

If any of the errors persist even after attempting the solutions mentioned earlier, refer to the "Testing the Lid Lock Assembly" section. The entire lid lock assembly may be the source of the issue, and it is advisable to perform a test on it.

Maytag Bravos XL washer lid lock stuck

These washers come equipped with a safety feature that prohibits them from being opened during a wash cycle. If you find yourself attempting to open the washer while it's mid-cycle, follow these steps:

1. First, press the pause button and wait for a few minutes to allow the washer to complete the draining process.
2. After the washer has drained, you can safely proceed to open the lid.
3. If the above steps do not work, the next course of action is to reset the washer. Simply disconnect it from the power outlet and let it sit for approximately five minutes.
4. Reconnect the washer to the power source, and you should now be able to open the lid.

Maytag Bravos XL washer lid lock bypass

A temporary repair option to consider is bypassing the lid lock on your Maytag Bravos XL washer. Here are two methods to achieve this:

Method 1: Using a Lego and a magnet

1. Insert a Lego into the lid lock slot.
2. Place the magnet on top of the Lego.
3. Your temporary bypass is now in place.

Method 2: Using a jumper wire

1. First, disconnect your washer from the power outlet and open it up to access the lid lock wire harness.
2. Insert the jumper wire into the blue (lid switch) and red (lock switch) wire slots of the harness.
3. Wrap the jumper wire securely using electrical tape to hold it in place.
4. Reconnect your washer to the power outlet and turn it on to check if it runs.
   • If the lid lock assembly was faulty, your washer should now be operational.

Conclusion

Addressing issues related to the lid lock on your Maytag Bravos XL washer can be crucial for ensuring its proper functioning. Error codes and clicking sounds often provide clues to the nature of the problem, and a variety of troubleshooting steps can be taken to resolve these issues. Additionally, it's important to be aware of the washer's safety mechanisms, which prevent the lid from being opened during a wash cycle.

If you encounter persistent problems or suspect a fault in the lid lock assembly, it may be necessary to perform tests or even replace the assembly. As a temporary measure, you can bypass the lid lock using methods such as Lego, a magnet, or a jumper wire.

These solutions can help you maintain the functionality of your Maytag Bravos XL washer and ensure a smooth laundry experience.
