Whirlpool top load washer diagnostic mode

A crucial action to take when addressing problems with contemporary Whirlpool top load washer diagnostic is to initiate diagnostic testing.

The rationale behind this is that when you execute a self-diagnostic procedure, various error codes may become visible, and these typically indicate the potential source of the issue.

Hence, provided below are the steps for activating the diagnostic mode on a Whirlpool top-loading washer when undertaking repairs:

Activating whirlpool top load washer diagnostic mode

To begin:

Ensure that the washing machine is in standby mode, meaning it is plugged in and all the indicators are switched off.

Procedure:

1. Select any three buttons (excluding the POWER button) and follow the steps below, using these same three buttons. It's important to remember both the three buttons and the order in which you press them.

Within 8 seconds:

1. Press and release your first selected button.
2. Press and release your second selected button.
3. Press and release your third-selected button.

Repeat the above sequence with the same three buttons two more times.

If the washer has entered the self-test diagnostic mode successfully, all the indicators on the console will light up for 5 seconds, "888" will be displayed in the 3-digit display, and you'll hear a tone sound.

Now, if the washer does not have any stored error codes, all the indicators on the console will briefly turn off. Then, you will see the seven-segment display return once more and display "888".

Please keep in mind that once you enter the service diagnostic test mode, all the cycles and options will reset to their factory default settings.

Unsuccessful Activation

If you have been unable to successfully enter the diagnostic mode, follow the following indications and suggested actions:

Indication 1:

• None of the indicators or displays turn on.

Recommended action:

• Go ahead and select any cycle.

Indication 2:

• Indicators do come on.

Recommended action:

• Attempt to change the function of the three buttons you used to activate the diagnostic test mode.
• If any of the buttons fail to change function, there may be a problem with that specific button, and you may not be able to enter the diagnostic mode using that button.
• The solution when buttons are malfunctioning is to replace the entire user interface.

Indication 3:

• No indicators light up after you select the cycle.

Recommended action:

• If no indicators illuminate after selecting the cycle, it is advisable to perform Test #1 (Main Control-ACU) because you may be dealing with a potentially faulty Main Control board.

Pros and Cons of Whirlpool Top Load Washer

Pros

• Reliability
• Variety of Models
• Efficiency
• Advanced Technology

Cons

• Space Requirements
• Water Usage
• Loading and Unloading
• Vibration and Noise

Differences Between Whirlpool top-load washer and LG washers

Whirlpool

Whirlpool top-load washers typically have a more traditional design with a top-loading drum and a control panel on the rear or top of the machine.

LG

LG offers a range of washing machines, including top-load models, with modern and sleek designs. They often have front control panels and a larger, transparent glass lid.

Read Also: Why Whirlpool Dryer Won't Start

Alternative to Whirlpool top-load washer

Samsung Top-Load Washers

Samsung produces top-load washers with features like Super Speed, Active WaterJet, and convenient smartphone connectivity.

Whirlpool top-load washer diagnostic codes (error codes)

Whirlpool top-load washer error codes are typically displayed in the format of F# and E# (where "F#" signifies the suspected system or category and "E#" represents the specific component in question). Here are some key points to understand about these saved error codes:

1. Storage of Error Codes: Your Whirlpool top-loading washing machine can store up to eight (8) fault or error codes. These codes are indicative of issues that the washer has detected during its operation.
2. Accessing Error Codes: To access and review the stored error codes, you can press the 3rd button (as selected previously) multiple times. When the oldest error code is displayed, additional presses on the 3rd button will lead to a triple beep sound, followed by the presentation of the washer's most recent error code.
3. No Stored Error Codes: If each press of the 3rd button results in triple beeps and the display shows "888," this indicates that no saved error codes are currently present in the washer's memory.

For clarity on how to advance through the stored error or fault codes, please refer to the accompanying image.

Clearing Whirlpool top loading washer Fault Codes

To clear stored error codes in your Whirlpool top-load washer, follow these steps:

1. Put the washer into diagnostic mode as previously instructed.
2. After entering the diagnostic mode, press and hold the third button you used to enter the service diagnostic mode. Keep holding it for 5 seconds.
3. If the saved fault or error codes are successfully cleared, the seven-segment display will once again show "888," and you'll hear a beep sound.

Clearing the stored error codes can be a helpful step when troubleshooting your washer, especially if you've addressed the underlying issues that led to the error codes in the first place.

Conclusion

Understanding how to access and clear error codes in your Whirlpool top-load washer's diagnostic mode can be a valuable tool for troubleshooting and resolving issues with your appliance. These error codes provide insight into potential problems within the washer, allowing for a more targeted approach to repairs or maintenance. By following the prescribed steps, you can efficiently navigate the diagnostic mode, access error codes, and clear them as needed. This knowledge can help you keep your washer in optimal working condition and address any faults or malfunctions promptly.
